Heyford Park,
Upper Heyford
Camp Road,
Bicester
Oxfordshire
OX25 5HD

Set within 1,231 acres of Oxfordshire countryside, Dorchester Living is not only building over 700 new homes, but is also committed to offering much more than just houses. As community builders, our approach focuses on providing a wide range of facilities and amenities, creating the foundations for Heyford Park’s reputation as a desirable and forward-thinking destination.

Access Panels supplied on site:

FF/060/PD/BF/BL

Plasterboard Faced Dual Purpose Access Panel with a Beaded Door, Supplied with the Patented FlipFix Fitting Device, Supplied with the Fast fit Hinge System, 1 Hour fire rated, Plasterboard Door, Beaded Frame, Budget Lock, Single Door Unit, Powder Coated RAL 9010 30% Gloss. The first dimension stated is the hinge side. This panel has a Fire Test Certificate up to 600x600mm in a Ceiling & Wall application covered by Fire Certificate Number WF380206 to BS EN 1364-2: 1999 and BS EN 1363-1: 2012. Anything above these sizes will be manufactured to the same construction as tested.

R12/060/MD/PF/L12A

Metal Faced Insulated Loft Hatch Ceiling Access Panel, 1 Hour fire rated, Metal Door, 25mm wide Picture Frame, 3 Point Locking System, Single Door Unit, Powder Coated RAL 9010 30% Gloss, the 1st dimension stated is the hinge side. This panel has a Fire Test Certificate up to 575x740mm in a Ceiling application covered by Fire Certificate Number 221643 tested in accordance with BS 476: Part 22: 1987. Anything above these sizes will be manufactured to the same construction as tested. THIS PRODUCT MUST BE INSTALLED INTO A VENTED ROOF SPACE



R15/000/PL/PF/NL

Wall Access Panel, Non Fire Rated, Plastic Panel, Picture Frame, Single Door Unit, White in Colour, the 1st dimension stated is the hinge side. (Not recommended for ceiling use).



R05/055/MD/PF/L12A/L14A/ATN/40A/RW/SD04

Metal Faced Ceiling Access Panel, 55 Minute fire rated, Metal Door, 25mm wide Picture Frame, 3 Point Locking System, Key Retaining Tamper Proof Key lock, Single Door Unit, Airtight Panel, 66.5mm Deep frame, 40 dB Acoustic Rated, RW3 Rockwool Infill to the Door Tray, Fitted with Safety Wires Powder Coated RAL 9010 30% Gloss, the 1st dimension stated is the hinge side. This panel has a Fire Test Certificate up to 1800x1800mm in a Ceiling application covered by Fire Certificate Number 252171 Tested as a Double Door Unit. Anything above these sizes will be manufactured to the same construction as tested. The Panel is Air Pressure to 75pa tested in accordance with BS 5368: Part 1, 1976 methods of testing covered by Certificate Number P02023.The panel is Acoustic Rated up to 40dB in a Ceiling application covered by Certificate Number TE 251449 tested in accordance with BS EN ISO 140-3:1995. Single number quantities were calculated in accordance with BS EN ISO 717-1:1997.



R01/000/MD/PF/L16A/RO/ATS/SS/316/9010

Metal Faced Dual Purpose Shallow Access Panel with extending fixing tabs, Non fire rated, Metal Door, 25mm wide Picture Frame, Suited Castellated Tamper Proof Key lock, Single Door Unit, Run off to the bottom of the frame to disperse water, Panel is only Shower Resistant not Water Tight, Airtight Panel, 316 Grade Mill Finish Stainless Steel, Powder Coated RAL 9010 30% Gloss. The 1st dimension stated is the hinge side.



R02/060/MD/BF/L12A/L14A/ATN/40A/9002

Metal Faced Wall Access Panel, 1 Hour fire rated, Metal Door, Beaded Frame, 3 Point Locking System, Key Retaining Tamper Proof Key lock, Single Door Unit, Airtight Panel, 40 dB Acoustic Rated, Powder Coated RAL 9002 30% Gloss, the 1st dimension stated is the hinge side.This panel has a Fire Test Certificate up to 2000x900mm in a Wall application covered by Fire Certificate Number 238923. Anything above these sizes will be manufactured to the same construction as tested.The panel is Acoustic Rated up to 40dB in a Wall application covered by Certificate Number TE 251449 tested in accordance with BS EN ISO 140-3:1995. Single number quantities were calculated in accordance with BS EN ISO 717-1:1997.

Project Value £6,000,000
